HI90060x

Photometric Electrodes

$529.99

For many titrations, a potentiometric determination of the equivalence point is simply not possible. In these cases, the use of a photometric probe for the optical determination of an endpoint during volumetric analysis is preferred. Hanna Instruments introduces HI90060x Series for when a color change is still the best solution.

4 different wavelengths
Less maintenance
Ideal for colorimetric reactions

Learn More

Thank you for your interest in our products. A representative will contact you within the next business day.

Across the Spectrum

Adding to our titration line, these probes are available in 4 different wavelengths from 470 nm to 625 nm. The HI90060X family of photometric probes use the principle of absorbance at a specific wavelength to identify the equivalence point of a titration with the use of a color indicator.

Specialized Construction

A glass construction minimizes chemical compatibility issues. The stainless steel shield within the glass blocks out ambient light and protects against any grounding loop current that may result in progressive damage of the probe.

Made to Fit

With a 12 mm diameter and 120 mm standard insertion length, these photometric electrodes fit easily into electrode holders. These probes have a universal BNC connector that is used as a potentiometric input on Hanna titrators and autosamplers.

hi900604-photometric-electrode-titrator-holder

Reflective Measurement

Each probe has a LED at a specific wavelength that shines light through the sample and is reflected back by a platinum mirror sealed in the glass. The reflective measurement has a fixed path length and allows for high color sensitivity in a compact design.

Less Maintenance

With the photometric probe there is no fill solution to change in order for it to be compatible with a non-aqueous sample and there is no pH sensor to foul.

For Colorimetric Reactions

The use of a photometric probe for potentiometric titration can be used for a variety of complexometric titrations. The photometric probe is also ideal for non-aqueous titrations.

Resources

Specifications

Specification Name	Detail
sku	HI90060x
mV Range	10 to 1100 mV
Wavelength / LED color	HI900601 @ 525 nm / green LED HI900602 @ 625 nm / red LED HI900603 @ 590 nm / yellow LED HI900604 @ 470 nm / blue LED
Light Source	LED
Measuring Cycle	LED pulsed at 1 kHz
Light Detector	silicon photocell
Sample Temperature	0 to 75°C (32 to 167°F)
Body Material	glass
Body Length / Overall Length	122 mm / 200mm
Outer Diameter	12 mm
Connection	BNC with 1.5 meter cable for connecting to titrator or autosampler
Power supply	ps/2 connector for connecting to titration system
Environment	0 to 50°C (32 to 122°F)
Ordering Information	Supplied with instruction manual and electrode quality testing certificate.

Product Manuals

IST90060X_06_19 Download
