Better Features for Better Testing
Let your photometer guide you through setup, calibration, and testing with on-screen tutorials and animations so you always know the next step. Simply access Tutorial Mode at any stage in the setup or measurement process with the dedicated help key.
The auto-off feature prolongs battery life for peace-of-mind and energy savings if the meter is accidentally left on.
When the battery level is below 10%, a warning symbol will blink to indicate low battery condition. When low battery power may affect your results, the meter will shut down to avoid erroneous readings caused by low battery level.
Missed a measurement? No need to worry because your photometer will automatically log the last 50 measurements. The results can be viewed instantly using the Log Recall Menu.
CAL Check Validation
Hanna’s exclusive CAL Check feature provides a stress-free, straightforward way to ensure your photometer is working properly. Simply insert the certified CAL Check standards and let your meter guide you through validation. If your photometer is out of specification for any reason, simply calibrate to your standard.
Advanced Optical System
A Light Emitting Diode (LED) provides more light while using less power and a narrow band interference filter results in more accurate and repeatable readings.
Designed to withstand the knocks, drops, and spills of real life, the new IP67 body ensures top performance in any environment. Internal optics are sealed from outside dust, dirt, and water. In addition, it floats, just in case you drop your meter in water. This photometer uses an exclusive positive‑locking system to ensure that the cuvettes are placed into the holder in the same position for accurate readings every time.
Made to fit comfortably in your hand for on-the-go testing or sit on a table for benchtop use, a backlit LCD display provides at-a-glance readings from any angle, day or night. The supplied AA batteries provide life for more than 800 measurements.
We believe that buying a meter should be simple. Your HI97104 photometer has many of the necessary accessories needed for successful measurements.Each HI97710 is supplied with:• Sample cuvette (2 pcs.)• Sample cap (2 pcs.)• Plastic stopper (2 pcs.)• Alkaline batteries: 1.5V AA (3 pcs.)• Instruction manual• Meter quality certificate
Upgrade to the pH, Alkalinity, Free Chlorine, Total Chlorine and Cyanuric Acid Photometer Kit (includes the CAL Check Standards) for the most economical option for testing.Each HI97104C is supplied with:• Sample cuvette (2 pcs.)• Sample cap (2 pcs.)• Plastic stopper (2 pcs.)• A ZERO ‑ CAL Check Cuvette A• HI97701B ‑ CAL Check Cuvette B for Free and Total Chlorine (Powder & Liquid)• HI97710B ‑ CAL Check Cuvette B for pH• HI97722B ‑ CAL Check Cuvette B for Cyanuric Acid• HI97775B ‑ CAL Check Cuvette B for Alkalinity• Cloth for wiping cuvettes• Scissors• Alkaline batteries: 1.5V AA (3 pcs.)• Instruction manual• Meter quality certificate• CAL Check standard certificate
Light Source light emitting diode Bandpass Filter Bandwidth 8 nm Bandpass Filter Wavelength Accuracy ±1.0 nm Light Detector silicon photocell Cuvette Type round, 24.6 mm diameter
pH Range 6.5 to 8.5 pH pH Resolution 0.1 pH pH Accuracy (@25ºC/77ºF) ±0.1 pH pH Method Adaptation of Phenol Red method
Free Chlorine and Total Chlorine Specifications
Chlorine Range 0.00 to 5.00 mg/L (ppm) Cl2 Chlorine Resolution 0.01 mg/L Chlorine Accuracy ±0.03 mg/L (ppm) ±3% of reading Chlorine Method Adaptation of US EPA method 330.5, DPD Colori metric method
Cyanuric Acid Specifications
Cyanuric Acid Range 0 to 80 mg/L (ppm) cyanuric acid Cyanuric Acid Resolution 1 mg/L Cyanuric Acid Accuracy ±1 mg/L ±15% of reading Cyanuric Acid Method Adaptation of the turbidimetric method
Display 128 x 64 pixel B/W LCD with backlight Auto-off After 15 minutes of inactivity (30 minutes before a READ measurement) Environment 0 to 50 °C (32 to 122 °F); 0 to 100% RH, non‑serviceable Weight 380 g (13.4 oz.) Battery Type Alkaline 1.5 V AA (3 pcs.) Dimensions 142.5 x 102.5 x 50.5 mm (5.6 x 4.0 x 2.0") Ordering Information
Each HI97104 is delivered in a cardboard box and is supplied with:• Sample cuvette (2 pcs.)• Sample cuvette cap (2 pcs.)• Plastic stopper (2 pcs.)• 1.5V AA Alkaline batteries• Instruction manual• Meter quality certificate
Each HI97104C is delivered in a rugged carrying case and is supplied with:• Sample cuvette (2 pcs.)• Sample cuvette cap (2 pcs.)• Plastic stopper (2 pcs.)• A ZERO‑ CAL Check Cuvette A• HI97701B ‑ CAL Check Cuvette B for Free and Total Chlorine (Powder & Liquid)• HI97710B ‑ CAL Check Cuvette B for pH• HI97722B ‑ CAL Check Cuvette B for Cyanuric Acid• HI97775B ‑ CAL Check Cuvette B for Alkalinity• Cloth for wiping cuvettes• Scissors• 1.5V AA Alkaline batteries• Instruction manual• Meter quality certificate• CAL Check standard certificates (4 pcs.)
Warranty 2 years
