HI762A

Air and Gas Thermistor Probe with Handle - HI762A

Name: Air and Gas Thermistor Probe with Handle - HI762A
SKU: HI762A
Price: 119.99 USD
Availability: InStock

$119.99

Current Stock:

Quantity:

Adding to cart… The item has been added

The HI762A is an air and gas thermistor probe with a handle designed for use with a thermistor thermometer. A cable extends 1 m (3.3') from the handle to the meter connection. The vent holes at the tip of the probe allow users to obtain highly accurate temperature readings of air and gases.

Measures up to 150°C (302°F)
6 second response time
AISI 316 stainless steel

The Air and Gas Thermistor Probe with Handle - HI762A is designed to measure the temperature of air and gas samples. The response time of a measurement is affected by the position of the sensor relative to the surface being measured. The HI762A construction with vent holes located at the tip of the probe offers a 6-second response for a temperature reading. With a strong, corrosion-resistant, AISI 316 stainless steel construction, this probe is able to measure samples up to 150°C (302°F).

Dimennsions HI762A

Resources

Specifications

Specification	Detail
SKU	HI762A
Reference	NTC thermistor
Accuracy (@25˚C/77˚F)	±0.2°C (±0.4°F)
Recommended Operating Temperature	-50 to 150°C (-58 to 302°F)
Response Time (90% of final value)	5 seconds
Body Length	L 100 mm x dia 3 mm (3.9 x 0.12)
Temperature Sensor	yes
Body Material	AISI 316 stainless steel
Cable	PVC/straight 1 m (3.3')
Recommended Use	air, gases
Connection	RCA

Air and Gas Thermistor Probe with Handle - HI762A
