pH/ORP/ISE and EC/TDS and DO Benchtop Meter Starter Kit

HI6553

pH/ORP/ISE and EC/TDS and DO Benchtop Meter Starter Kit

$1,799.99

Set yourself up for testing success with our pH/ORP/ISE and EC/TDS and DO Benchtop Meter Starter Kit (HI6553). There are two options available to choose from, our opdo® kit which includes an opdo® probe or our DO kit which includes a polarographic DO probe. Our high-performing benchtop meter is ready-to-use straight out of the box and is fully equipped with everything you need to test. Includes necessary modules, electrodes, solutions, and more.

Precise and consistent. Achieve quick, accurate, and repeatable results
Reliable and efficient. Ensure quality and meet requirements with easy digital record keeping and increased traceability
Simple and straightforward. Intuitive navigation menus, built-in help guides, and video tutorials make testing hassle-free

Fits seamlessly into any laboratory or industry environment.

Perfect for chemists, researchers, educators, food manufacturers, beverage producers, and metal finishers to name a few.

Learn More

Thank you for your interest in our products. A representative will contact you within the next business day.

Resources

What's included with our pH/ORP/ISE and EC/TDS and opdo® Starter Kit
- Multiparameter Modular System (HI6000-01)
- pH/ORP/ISE Module (HI6000-2) (1 pc.)
- EC/TDS Module (HI6000-3) (1 pc.)
- DO Module (HI6000-4) (1 pc.)
- pH Electrode with BNC Connector (HI1131B) (1 pc.)
- Temperature Probe (HI7662-TW) (1 pc.)
- EC/TDS Probe (HI7631233) (1 pc.)
- opdo^®Probe (HI7641133) (1 pc.)
- pH 4.01 Buffer Solution Sachets (2 pcs.)
- pH 7.01 Buffer Solution Sachets (2 pcs.)
- pH 10.01 Buffer Solution Sachets (2 pcs.)
- Electrode Cleaning Solution Sachets (HI700601) (2 pcs.)
- pH and ORP Electrode Storage Solution 25 mL (HI70300S) (1 pc.)
- 3.5M KCl Electrolyte Solution 30 mL (HI7082) (1 pc.)
- 1413 µS/cm Conductivity Standard Solution Sachets (HI70031P) (2 pcs.)
- 5000 µS/cm Conductivity Standard Solution Sachets (HI70039P) (2 pcs.)
- 12880 µS/cm Conductivity Standard Solution Sachets (HI70030P) (2 pcs.)
- Electrode Rinse Solution Sachets (2pcs.)
- Capillary Pipette (1 pc.)
- DO Smart Cap with O-ring (1 pc. of each)
- Calibration/Storage Vessel (1 pc.)
- Lens Cleaning Wipe (1 pc.)
- Syringe and Sachet with Silicon Grease (1 pc. of each)
- Electrode Holder (HI764060) (1pc) The following accessories include: base plate with integrated pivot pin and screw (requires installation), attached cable holder clip, attached electrode holder with adapter
- 24 VDC Power Adapter (1 pc)
- USB-C to USB-A Cable (1 pc)
- Meter Quick Reference Guide (1 pc.)
- Meter, Smart Cap, and Probes Quality Certificates
- Modules Hardware Quick Reference Guide and Quality Certificates
What's included with our pH/ORP/ISE and EC/TDS and DO Starter Kit
- Multiparameter Modular System (HI6000-01)
- pH/ORP/ISE Module (HI6000-2) (1 pc.)
- EC/TDS Module (HI6000-3) (1 pc.)
- DO Module (HI6000-4) (1 pc.)
- Refillable Combination pH Electrode with BNC Connector (HI1131B) (1 pc.)
- Temperature Probe (HI7662-TW) (1 pc.)
- EC/TDS Probe (HI7631233) (1 pc.)
- Polarographic DO Probe (HI764833) (1 pc.)
- pH 4.01 Buffer Solution Sachets (2 pcs.)
- pH 7.01 Buffer Solution Sachets (2 pcs.)
- pH 10.01 Buffer Solution Sachets (2 pcs.)
- Electrode Cleaning Solution Sachets (HI700601) (2 pcs.)
- pH and ORP Electrode Storage Solution 25 mL (HI70300S) (1 pc.)
- 3.5M KCl Electrolyte Solution 30 mL (HI7082) (1 pc.)
- Polarographic DO Electrolyte Solution (30 mL) (HI7041S) (1 pc.)
- 1413 µS/cm Conductivity Standard Solution Sachets (HI70031P) (2 pcs.)
- 5000 µS/cm Conductivity Standard Solution Sachets (HI70039P) (2 pcs.)
- 12880 µS/cm Conductivity Standard Solution Sachets (HI70030P) (2 pcs.)
- Electrode Rinse Solution Sachets (2pcs.)
- Capillary Pipette (1 pc.)
- DO Membrane Cap with O-ring (2 pcs.)
- Electrode Holder (HI764060) (1pc) The following accessories include: base plate with integrated pivot pin and screw (requires installation), attached cable holder clip, attached electrode holder with adapter
- 24 VDC Power Adapter (1 pc)
- USB-C to USB-A Cable (1 pc)
- Meter Quick Reference Guide (1 pc.)
- Meter and Probes Quality Certificates
- Modules Hardware Quick Reference Guide and Quality Certificates

Specifications

Specification Name	Detail
Sku	HI6553
pH Range	-2.0 to 20.0 pH; -2.00 to 20.00 pH; - 2.000 to 20.000 pH
pH Resolution	0.1 pH; 0.01 pH; 0.001 pH
pH Accuracy	±0.1 pH; ±0.01 pH; ±0.002 pH (±1 last significant digit)
Calibration Points	Up to 5
Calibration Type	Automatic; Semiautomatic; Manual
Standard Buffers	Hanna and NIST (pH 1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45)
Custom Buffers	Up to 5
Custom Group	Option to select from eight standard buffers and user-defined custom buffers
First Calibration Point	Offset or Point (user setting)
Isopotential Point	-2.000 to 20.000 pH
mV Range	-2000.0 to 2000.0 mV
mV Resolution	1 mV; 0.1 mV
mV Accuracy	±0.2 mV ±1 last significant digit
mV Calibration	Single point offset, ±2000.0 mV
ISE Range	1.0×10^¯5 to 300.0 ppt (g/L or mg/mL) 5.0×10^¯3 to 1.0×10⁵ ppm (mg/L or µg/mL) 1.0 to 5.0×10⁷ ppb (µg/L) 1.0×10^¯7 to 10.0 M (mol/L) 1.0×10^¯4 to 1.0×10⁴ mmol/L 1.0×10^¯6 to 60.0 %w/v 5.0×10^¯7 to 5.0×10⁷ user
ISE Resolution	1, 2, 3 significant digits
ISE Accuracy	±0.5% (monovalent ions); ±1% (divalent ions)
ISE Calibration Points	Up to 5
ISE Calibration Type	All Standards; Standard Group
ISE Standards	7 standard solutions available for each concentration unit
ISE Custom Standards	Up to 5
ISE Custom Group	Up to 5
Conductivity Range	0.000 to 9.999 μS/cm; 10.00 to 99.99 μS/cm; 100.0 to 999.9 μS/cm; 1.000 to 9.999 mS/cm; 10.00 to 99.99 mS/cm; 100.0 to 1000.0 mS/cm
Conductivity Resolution	0.001 μS/cm; 0.01 μS/cm; 0.1 μS/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1 mS/cm
Conductivity Accuracy	±1 % of reading or ±0.010 μS/cm, whichever is greater
Conductivity Cell Constant	0.0500 to 200.0000 /cm
Conductivity Calibration Type	Automatic; Manual
Conductivity Calibration Points	Single; Up to 5
Conductivity Calibration Solutions	84 μS/cm; 1413 μS/cm; 5000 μS/cm; 12880 μS/cm; 80000 μS/cm; 111800 μS/cm
Resistivity Range	1.0 to 99.9 Ω•cm; 100 to 999 Ω•cm; 1.00 to 9.99 KΩ•cm; 10.0 to 99.9 KΩ•cm; 100 to 999 KΩ•cm; 1.00 to 9.99 MΩ•cm; 10.0 to 100.0 MΩ•cm
Resistivity Resolution	0.1 Ω•cm; 1 Ω•cm; 0.01 KΩ•cm; 0.1 KΩ•cm; 1 KΩ•cm; 0.01 MΩ•cm; 0.1 MΩ•cm
Resistivity Accuracy	±1 % of reading or ±1 Ω•cm, whichever is greater
Total Dissolved Solids (TDS) Range	0.000 to 9.999 ppm; 10.00 to 99.99 ppm; 100.0 to 999.9 ppm; 1.000 to 9.999 ppt; 10.00 to 99.99 ppt; 100.0 to 400.0 ppt; actual TDS (with 1.00 factor)
Total Dissolved Solids (TDS) Resolution	0.001 ppm; 0.01 ppm; 0.1 ppm; 0.001 ppt; 0.01 ppt; 0.1 ppt
Total Dissolved Solids (TDS) Accuracy	±1 % of reading or ±0.01 ppm, whichever is greater
Salinity Range	0.00 to 42.00 PSU (Practical Salinity Scale); 0.00 to 80.00 ppt (Natural Sea Water); 0.0 to 400.0 % (Percent Scale)
Salinity Resolution	0.01 PSU; 0.01 ppt; 0.1 %
Salinity Accuracy	±1 % of reading
Salinity Calibration	1 point, using 100 % salinity calibration solution (% scale only)
Salinity Compensation	Manual > 0.00 to 45.00 PSU or ppt > 0.0 to 130.0 %
DO Range	0.0 to 500.0 % saturation; 0.00 to 90.00 mg/L (ppm) concentration
DO Resolution	0.1 % saturation; 0.01 mg/L (ppm)
DO Accuracy	Refer to probe used
DO Calibration Points	One or two points at 100.0 % (8.26 mg/L) and 0.0 % (0.00 mg/L)
DO Calibration Type	Automatic; Manual (user entered value in % saturation, mg/L, or ppm)
Barometric Pressure Range	450.0 to 850.0 mmHg; 600.0 to 1133.2 mbar; 60.00 to 113.32 kPa; 17.72 to 33.46 inHg; 8.702 to 16.436 psi; 0.5921 to 1.1184 atm
Barometric Pressure Resolution	0.1 mmHg; 0.1 mBar; 0.01 kPa; 0.01 inHg; 0.001 psi; 0.0001 atm
Barometric Pressure Accuracy	±3 mmHg within ±15 % from calibration point; ±3 mmHg ±1 least significant digit
Barometric Pressure Compensation	Automatic (meter-integrated barometer); Manual
Temperature Range	−20.0 to 120.0 °C; −4.0 to 248.0 °F; 253.2 to 393.2 K
Temperature Resolution	0.1 °C; 0.1 °F; 0.1 K
Temperature Accuracy	For pH and conductivity: ±0.2 °C; ±0.4 °F; ±0.2 K For DO: Refer to probe used
Temperature Calibration	Single point, adjustable
Temperature Compensation	For pH and DO: Automatic; Manual For Conductivity: Linear; Natural; Standard; Disabled
Reference Temperature	For Conductivity: 5.0 to 30.0 °C (41.0 to 86.0 °F , 278.2 to 303.2 K)
Temperature Coefficient	For Conductivity: 0.00 to 10.00 %/°C
Reading Mode	Direct Direct/Autohold For ISE Only: Known Addition, Known Subtraction, Analyte Addition, Analyte Subtraction For Conductivity: Direct/USP For DO Only: OUR, SOUR, BOD
Basic View	Measurement data; Measurement profile (if enabled); Stability status
Simple GLP View	Basic view information For pH: Last calibration date, slope, offset (pH, Rel. mV - ISE only) For Conductivity: Last calibration date and offset For DO: Last calibration date, offset, average slope
Full GLP View	Simple GLP Information; Calibration point details (pH, ISE, conductivity, salinity, and DO)
Graph View	Basic view information; Measurement versus time graph
Table View	Basic view information; Table with measurements updated every second
Reading Stability Criteria	Accurate; Medium; Fast
Reading Sampling Rate	1000 ms
Logging Type	Automatic; Manual; Autohold
Logging Number of Records	50,000 maximum per file and stores at least 1,000,000 data points per user
Logging Automatic Interval	1, 2, 5, 10, 30 seconds and 1, 2, 5, 10, 15, 30, 60, 120, 150, 180 minutes
Logging Sample ID	Incremental Mode; Manual
Logging Export Option	.CSV file format
Connectivity USB-A	2 ports keyboard and/or printer input USB Flash Drive
Connectivity USB-C	1 port PC Connectivity and USB-C Type Flash Drive
Connectivity Wi-Fi & Ethernet	FTP; Web Server (Log transfer and download); Email
Connectivity RS232	Connecting peripherals
Calibration Reminder	Daily (0 minutes to 23 hours and 59 minutes); Periodic (1 minute to 30 Days, 23 hours and 59 minutes); or Disabled
Users	Up to 9 users and the default administrator account
Power Supply	DC adapter 100-240 VAC to 24 VDC 2A
Environment	0 to 50 °C / 32 to 122 °F / 273 to 323 K maximum 95 % RH non-condensing
Dimensions	205 x 160 x 77 mm (8.0 x 6.2 x 3.0 ")
Weight	8.05 lbs

Features
- This benchtop has a 7-inch touch screen color display (800 x 480p resolution)
- Up to 3 hardware modules can be installed on this benchtop. The installed hardware module is assigned to the measurement channel
- Up to 3 measurements can be displayed on the benchtop screen at one time and format options can be changed in settings
- Customize measurement and calibration options, create custom buffers, and more
- Equipped with a measurement stability indicator. This criteria can be adjusted in settings
- There are reading or module specific application modes (direct and direct/autohold)
- There's no need to update the sensor or benchtop system settings with application-specific probes for direct measurements
- Temperature compensation can be automatic when using a temperature probe or integral temperature sensor within probe. This can also be set manually
- Galvanic isolation for measurement modules
- Non-volatile memory saves data and settings
- Users can create alarms to be notified when parameters are out of desired ranges. Warnings will appear on the message banner and a beeping noise will sound if enabled
- Determine appropriate permission and password settings for each user, administrator or standard level, to prevent unwanted edits or changes to benchtop options and results
- Includes help menu for support with a brief overview of the main functionalities with descriptions and video tutorials
Connection Options
- Users can select the network to be connected via Ethernet, Wi-Fi, or disabled
- Conveniently transfer logged data as a .CSV file via email or FTP with Ethernet and Wi-Fi connection
- Export data via a USB Flash Drive or direct PC connection
- Download logs to a web client with the embedded web server
- Utilize a Thermal Printer (SP6000-PRN01) or keyboard with this benchtop via a USB-A port
- Up to 2 Mini Magnetic Stirrers (HI6000180) can be connected to this device via the two ports located on the back of the benchtop. Set the stirrer speed and the rotation direction
- This benchtop meter works with Hanna Instruments pH electrodes with a BNC connection
Reporting Capabilities
- Active data logging during measurement
- Includes three data-logging types: manual, automatic, and auto-hold
- Record up to 1 million data points with time and date stamp for easy reference. Sample ID is also documented which is ideal for manual and auto-hold data collection
- Method-specific application reports can be generated
Product Manual

Multiparameter Modular System Manual Download

Easily modify your view options to suit your preferences

Up to 3 measurements can be shown on the benchtop screen at the same time. Various display configurations and formats are available and can be adjusted in settings.

Single-parameter screen

Dual-parameter screen

HI6000-Triple-Basic-Display-Screen-800x460-C

Triple-parameter screen

Double up on the testing with an additional Electrode Holder

Electrode Holder
HI764060 $139.99

Multitasking has a new meaning in the lab. Optimize your time by incorporating another electrode holder as part of your testing processes. Having not just one, but two electrode holders will allow you to test more samples and expand your bandwidth.

Utilize a Mini Magnetic Stirrer to ensure sample consistency

Mini Magnetic Stirrer
HI6000180 $219.99

Streamline sample handling with a Mini Magnetic Stirrer. This piece of testing equipment automatically stirs for you, so that you can focus on other important tasks. Easily control the stirring speed and rotation direction by adjusting the slider on the benchtop screen or using the knob located on the front of the stirrer. Two stirrers can be connected to the benchtop at the same time.

Save time and maximize efficiency with a Thermal Printer

Thermal Printer
SP6000-PRN01 $679.99

Integrating a Thermal Printer as part of the quality assurance process is required in certain laboratories. Plus, it is a nice-to-have for added convenience. With its compact size, this printer takes up minimal space, making it an ideal choice for a lab setting. This printer simply connects to our pH/ORP/ISE and EC/TDS and DO Benchtop Meter (HI6553). Quickly print and share data reports on the spot.
